35khz 1200W Servo Digital Ultrasonic Welding Machine Remote Control Supportable
35khz 1200W Intelligent Digital Ultrasonic Welding Machine Remote Control Supportable
Technical Parameters:
| Model | iSF S3512e |
| Frequency accuracy | 34.80KHz-35.20KHz |
| Power | 1200W |
| Triggering Method | Position/Pressure/Pressure drop |
| Welding Method | Weld time/relative position/absolute position/ weld energy/peak power/Max.pressure/grounding detect |
| Effective stroke(mm) | ≤75mm |
| Max Welding Time | 5 S |
| Voltage(V) | AC220V±5% 50/60Hz |
| Amplitude control | Single-stage amplitude/stepping amplitude/distance amplitude |
| Piling function | Time /position/energy/pressure |
| Operation way | standard/multi-speed(9-speed) |
| Cooling system | Vortex cooler |
| Weld area | No more than 40mm as per material, shape, etc. |
| Dimension(L*W*H)mm | 350*530*1360mm |
| Weight(kg) | 80kg |
More models are available:
| Model | iSF S2025e | iSF S2030e | iSF S2040e | iSF S3015e | iSF S3512e | iSF S4008e |
| Frequency /KHz | 20KHz | 20KHz | 20KHz | 30KHz | 35KHz | 40KHz |
| Power/W | 2500W | 3000W | 4000W | 1500W | 1200W | 800W |
| Trigger mode | Position/Pressure/Pressure drop | |||||
| Weld mode | Weld time/relative position/absolute position/weld energy/peak power/Max.pressure/grounding detect | |||||
| Effective stroke/mm | ≤95mm | ≤75mm | ||||
| Pre-oscillation function | 1)OFF 2)Pre-oscillation time 3)Pre-oscillation position | |||||
| Amplitude control | Single-stage amplitude/stepping amplitude/distance amplitude | |||||
| Piling function | Time /position/energy/pressure | |||||
| Operation way | standard/multi-speed(9-speed) | |||||
| Max.weld time | 5 seconds | |||||
| Voltage power supply(V) | AV220V±5% 50/60Hz | |||||
| Size(L*W*H)mm | 400*670*1610mm | 350*530*1360mm | ||||
| Weight (kg) | 105kg | 80kg | ||||
Features:
* 9-stage speed and pressure control for operation at super high speed, and intelligent drive system makes this welder 6-Sigma repeatability, which contributes to the stability, precision, and reliability of Dongho brand ultrasonic welders.
* The new type of weighing sensor can sense the force and data display, which enables better control of the trigger force and welding force.
* Superposition function: Four types of welding processes can meet the demand for some special applications.
* Advanced UTC multi-core control system has enhanced the performance greatly in several folds, in conjunction with self-developed electromechanical adjustment-free function for ultra-precision control, connecting MES, DPS systems to PC has realized real-time data management.
* CAN bus for field management to make the handling of high-speed application procedures realizable
* The 6th generation iQS operating system with multi-level password protection.
* Advanced 7 welding modes.
* Intelligent functions and technologies(precise positioning, distance, and stacking functions)
Principle of ultrasonic plastic welding
Ultrasonic plastic welding is a new type of plastic processing technology. When welding plastic products, ultrasonic welding does not add any binder, filler, or solvent. It has the advantages of high efficiency, high quality, beautiful appearance, and energy saving. Through energy conversion system will generate high voltage and high-frequency signal generator is converted to high-frequency mechanical vibration, and added to the plastic workpiece, improve to the interface by friction between the workpiece temperature of the workpiece surface and internal molecules when the temperature reaches the melting point of the workpiece itself, the workpiece interface will quickly melt, when vibration stops, workpiece cooling forming under certain pressure, Fill the gap between the interface, the ultrasonic welding plastic strength can be close to the raw material strength, can achieve perfect welding effect.
