20Khz Ultrasonic Generator Box With Parallel Circuit for Ultrasonic Welder
This ultrasonic generator has the automatic frequency tracking and compensation function, which makes it quickly respond to the frequency fluctuation of the triplet resonant system and automatically save the best frequency as the next starting frequency. According to the real-time load change, the amplitude of the ultrasonic generator automatically compensates, to ensure the stability of the equipment amplitude output.
What's more, the starting rate is optional, ensuring the triplet stable and fast starting vibration. This type of ultrasonic generator has two welding modes of time and energy, and the generator gives warning signals to frequency offset, excessive current, excessive voltage, excessive temperature, and power overload.
This type of parallel circuit generator box based on advanced technology in China, applicable for food cutting, plastic welding, non-woven fabric welding, etc.
Technical parameters:
| Product Name | Ultrasonic Welding Generator 20kHz |
| Model | KM-JQ-G |
| Output power | 0-2500W |
| Voltage | 220V+/-10%, 50-60Hz |
| Working frequency | 15KHz/20KHz/28KHz/30KHz/35KHz/40KHz |
| Work temperature | -10 to +40℃ |
| Input/output interface | Plug-in type connectors |
| curing time adjustment range | 0-99.99s |
| Power fluctuation | ≤ 5% |
| Welding mode | time, energy |
Different models are available:
| Frequency | Output power | Voltage | Air source | Weight |
| 15kHz | 2600W,3000W,4200W(higher power can be customized.) | 220V+-10% | filtered clean air | 6kg |
| 20kHz | 1500W,2500W,3000W | |||
| 28kHz | 800W,1000W | |||
| 30kHz | 800W,1000W | |||
| 35kHz | 800W,1000W |
Features:
| * Real-time frequency automatic tracking function. |
| * Welding time is adjustable |
| * Cooling time is adjustable |
| * Welding amplitude adjustable 10%-100% (1% accuracy) |
| * Overload protection |
| * Voltage protection |
| * Transducer voltage protection |
Application:
non-woven welding, plastic welding, and food cutting industries.
For more details about our ultrasonic generators, welcome to click the catalog below:
Catalog of KnmTech Ultrasonic Generators.pdf
